• Air conditioning, dual-zone automatic climate control with individual climate settings for driver and right-front passenger
• Door locks, power
• Steering wheel controls, mounted audio controls

• Air cleaner, high-capacity
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Four wheel drive
• Recovery hooks, front, frame-mounted

• Brakes, 4-wheel antilock, 4-wheel disc
• Daytime Running Lamps, with automatic exterior lamp control
• OnStar Equipped (subscription required)

LTZ PREFERRED EQUIPMENT GROUP

• includes standard equipment

SEATS, FRONT BUCKET

• includes 10-way power driver and front passenger seat adjusters
• 2-way power lumbar control
• heated seat cushions and seatbacks
• 2-position driver memory
• adjustable outboard head restraints
• floor console and storage pockets (STD)

ENGINE, DURAMAX 6.6L TURBO DIESEL V8

• B5-Diesel compatible (365 hp [271.7 kW] @ 3200 rpm
• 660 lb-ft of torque [894.6 N-m] @ 1600 rpm) Includes (TUV) heavy-duty dual
• 730 cold-cranking-amp battery and (K05) engine block heater)

BATTERY, HEAVY-DUTY DUAL 730 COLD-CRANKING AMPS, MAINTENANCE-FREE

• with rundown protection and retained accessory power

TIRES, LT225/75R17E ALL-SEASON, BLACKWALL

• (STD) Includes 7 tires with (E63) Fleetside pickup box. Includes 6 tires with (ZW9) pickup box delete.)

TIRE, SPARE LT225/75R17E ALL-SEASON, BLACKWALL

• includes 17" (43.2 cm) steel spare wheel and spare tire carrier

AUDIO SYSTEM, AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER

• seek-and-scan
• digital clock
• auto-tone control
• Radio Data System (RDS)
• speed-compensated volume and TheftLock (STD)

GVWR, 11,400 LBS. (5171 KG)

• with dual rear wheels (STD)

SUNROOF, POWER

• with express-open
• includes (UG1) Universal Home Remote

MIRRORS, OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL CAMPER MANUAL-FOLDING AND EXTENSION, BLACK

• integrated turn signal indicators consisting of 50 square inch flat mirror surface positioned over a 20 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated or power adjustable)

TRANSMISSION, ALLISON 1000 6-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED

• with overdrive
• electronic engine grade braking and tow/haul mode

TRAILERING WIRING PROVISIONS, FOR CAMPER, FIFTH WHEEL AND GOOSENECK TRAILER

• includes additional 8-way wiring harness routed to front of pickup box

COVERS, RADIATOR GRILLE AND FRONT BUMPER OPENINGS

• for diesel engines in winter weather

PICKUP BOX, FLEETSIDE

• (STD)

SOLID PAINT

• (STD)

• 11,400 lbs (5,171 Kgs) GVWR
• 17' X 6.5' 8-Lug Painted Steel Wheels
• 3.73 Rear Axle Ratio
• Allison 1000 6-Speed Automatic Transmission with Overdrive
• Black
• Driver 10-Way Power Seat Adjuster
• Ebony
• Federal Emissions Requirements
• Front License Plate Bracket
• Front Passenger 10-Way Power Seat Adjuster
• Heated Vertical Camper Outside Mirrors
• Heavy-Duty Handling/trailering Suspension Package
• Power Sunroof with Express-Open
• Radiator Grille and Front Bumper Opening Covers
• Rear Audio System Controls
• Trailering Wiring Provisions
• Universal Home Remote
• AM/FM Stereo with MP3 Compatible CD Player
• Duramax 6.6L Turbo Diesel V8 Engine
• LT225/75R17E AS BW (6) Tires
• Preferred Equipment Group 1LZ
• 12V power outlets 4 12V power outlets
• 17' X 6.5' 8-Lug Painted Steel Wheels
• 3-point seatbelt Rear seat center 3-point seatbelt
• 4-Wheel Disc Brakes
• 4WD type Part-time 4WD
• A/C
• ABS
• ABS Brakes 4-wheel antilock (ABS) brakes
• ABS Brakes Four channel ABS brakes
• Accessory power Retained accessory power
• Adjustable Steering Wheel
• Air conditioning Yes
• Alternator Type Alternator
• AM/FM Stereo
• Amplifier
• Antenna Fixed audio antenna
• Armrests front center Front seat center armrest
• Armrests rear Rear seat center armrest
• Audio storage Audio media storage unit
• AUDIO SYSTEM AM/FM STEREO WITH MP3 COMPATIBLE CD PLAYER seek-and-scan digital clock auto-tone control Radio Data System (RDS) speed-compensated volume and TheftLock (STD)
• Audio theft deterrent THEFTLOCK audio system theft deterrent
• Auto door locks Auto-locking doors
• Auto headlights Auto on/off headlight control
• Auto-Dimming Rearview Mirror
• Automatic Headlights
• Aux input jack Auxiliary input jack
• Auxiliary power take-off
• Basic warranty 36 month/36,000 miles
• BATTERY HEAVY-DUTY DUAL 730 COLD-CRANKING AMPS MAINTENANCE-FREE with rundown protection and retained accessory power
• Battery charge warning
• Battery run down protection
• Battery type Dual lead acid batteries
• Beverage holders Front beverage holders
• Beverage holders rear Rear beverage holders
• Block heater Engine block heater
• Body panels Fully galvanized steel body panels with side impact beams
• Bodyside moldings Body-colored bodyside moldings
• Box style Standard style pickup box
• Brake type 4-wheel disc brakes
• Bucket Seats
• Bumper rub strip rear Black rear bumper rub strip
• Bumpers front Chrome front bumper
• Bumpers rear Chrome rear bumper
• Cab mounted cargo light
• Cabback insulator
• CD location CD player located in the dashboard/instrument panel
• CD Player
• CD Single-disc CD player
• CD-R compatible
• Child door locks Manual rear child safety door locks
• Clearance lights Cab clearance lights
• Climate Control
• Climate control Automatic climate control
• Clock Digital clock
• Compass
• Compressor Intercooled turbo
• Convex spotter Driver and passenger convex spotter mirrors
• Corrosion perforation warranty 72 month/100,000 miles
• COVERS RADIATOR GRILLE AND FRONT BUMPER OPENINGS for diesel engines in winter weather
• Cruise Control
• Cruise control Cruise control with steering wheel mounted controls
• Cylinder head material Aluminum cylinder head
• Day/Night rearview mirror
• Daytime Running Lights
• Delay off headlights Delay-off headlights
• Door ajar warning
• Door bins front Driver and passenger door bins
• Door handle material Body-colored door handles
• Door locks Power door locks with 2 stage unlocking
• Door mirror style Black door mirrors
• Door mirror type Manual extendable trailer mirrors
• Door mirrors Power door mirrors
• Door panel insert Simulated wood door panel insert
• Drive type Four-wheel drive
• Driver Adjustable Lumbar
• Driver Air Bag
• Driver Illuminated Vanity Mirror
• Driver information center
• Driver lumbar Driver seat with 4-way power lumbar
• Driver seat direction Driver seat with 8-way directional controls
• Driver Vanity Mirror
• Dual rear wheels
• Dual-zone front climate control
• EBONY ULTRASOFT LEATHER-APPOINTED SEAT TRIM
• Emergency SOS Capable OnStar Safe & Sound vehicle integrated emergency SOS system
• Emissions Federal emissions
• ENGINE DURAMAX 6.6L TURBO DIESEL V8 B5-Diesel compatible (365 hp [271.7 kW] @ 3200 rpm 660 lb-ft of torque [894.6 N-m] @ 1600 rpm) Includes (TUV) heavy-duty dual 730 cold-cranking-amp battery and (K05) engine block heater)
• ENGINE BLOCK HEATER
• Engine block material Iron engine block
• Engine Configuration Duramax V8
• Engine cooler Engine oil cooler
• Engine Duramax 6.6L V-8 diesel direct injection, intercooled turbo, diesel, engine with 365HP
• Engine hour meter
• Engine Location Front mounted engine
• Engine Mounting direction Longitudinal mounted engine
• Engine Short Duramax 6.6L V-8
• Engine temperature warning
• Engine/electric motor temperature gauge
• Equalizer Automatic audio equalizer
• First-row sunroof First-row sliding and tilting glass sunroof with express open/close activation sunshade
• First-row windows Power first-row windows
• Floor console Full floor console
• Floor console storage Covered floor console storage
• Floor coverage Full floor coverage
• Floor covering Full carpet floor covering
• Floor Mats
• Floor mats Rubber front and rear floor mats
• Fog Lamps
• Fog lights Front fog lights
• Folding door mirrors Manual folding door mirrors
• Folding rear seats 60-40 folding rear seats
• Four Wheel Drive
• Front anti-roll Front anti-roll bar
• Front head restraint control Manual front seat head restraint control
• Front head restraints Height adjustable front seat head restraints
• Front impact airbag driver Driver front impact airbag
• Front impact airbag passenger Cancellable front passenger air bag
• Front passenger lumbar Front passenger seat with 4-way power lumbar
• Front Reading Lamps
• Front reading lights
• Front seat upholstery Leather front seat upholstery
• Front seatback upholstery Plastic front seatback upholstery
• Fuel Type Diesel
• Garage door opener
• Gearshifter material Urethane gear shifter material
• Glove box Locking glove box
• Grille style Chrome grille
• GVWR 11 400 LBS. (5171 KG) with dual rear wheels (STD)
• Headlight type Reflector headlights
• Headlights Halogen headlights
• Headlights on reminder
• Headliner coverage Full headliner coverage
• Headliner material Cloth headliner material
• Heated door mirrors Heated driver and passenger side door mirrors
• Heated Front Seat(s)
• Heated front seats Heated driver and front passenger seats
• Heated Mirrors
• Heated wipers Heated washer fluid reservoir
• Height adjustable seatbelts Front height adjustable seatbelts
• High mount stop light High mounted center stop light
• Ignition Compression ignition system
• Ignition type Mechanical
• Illuminated entry
• Immobilizer PASSLock II immobilizer
• Instrumentation display Analog instrumentation display
• Interior accents Chrome interior accents
• Interior courtesy lights Fade interior courtesy lights
• Intermittent Wipers
• Internet access Selective service internet access
• Key in vehicle warning
• Keyfob keyless entry
• Keyfob remote start
• Keyless Entry
• Leather Seats
• Leather Steering Wheel
• LICENSE PLATE BRACKET FRONT
• License plate front bracket Front license plate bracket
• Lock-up transmission
• Locking hub control Auto locking hub control
• Locking/Limited Slip Differential
• Low level warnings Low level warning for coolant, fuel, washer fluid and brake fluid
• LTZ PREFERRED EQUIPMENT GROUP includes standard equipment
• Memory settings Memory settings include: door mirrors
• MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL CAMPER MANUAL-FOLDING AND EXTENSION BLACK integrated turn signal indicators consisting of 50 square inch flat mirror surface positioned over a 20 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated or power adjustable)
• MP3 Capability
• Multi-Zone A/C
• Multiple headlights Multiple enclosed headlights
• Number of airbags 2 airbags
• Number of doors 4 doors
• Number of memory settings 2 memory settings
• Oil pressure gauge
• Oil pressure warning
• One-touch down window Driver and passenger one-touch down windows
• Overdrive transmission
• Overhead console Mini overhead console
• Paint Non-metallic paint
• Panel insert Simulated wood and metal-look instrument panel insert
• Pass-Through Rear Seat
• Passenger Adjustable Lumbar
• Passenger Air Bag
• Passenger doors rear left Conventional left rear passenger door
• Passenger doors rear right Conventional right rear passenger door
• Passenger Illuminated Visor Mirror
• Passenger seat direction Front passenger seat with 8-way directional controls
• Passenger Vanity Mirror
• Perimeter approach lighting Remote activated perimeter approach lighting
• Power Door Locks
• Power Driver Seat
• Power driver seat controls Driver seat power reclining, lumbar support, cushion tilt, fore/aft control and height adjustable control
• Power Mirror(s)
• Power Outlet
• Power Passenger Seat
• Power passenger seat controls Passenger seat power reclining, lumbar support, cushion tilt, fore/aft control and height adjustable control
• Power Steering
• Power Windows
• Powertrain type ICE
• Powertrain warranty 60 month/100,000 miles
• Premium Sound System
• Privacy Glass
• Radiator
• Radio AM/FM/XMsatellite
• RDS Radio data system (RDS)
• Rear audio controls Multi-source rear audio controls
• REAR AXLE 3.73 RATIO
• Rear Bench Seat
• Rear bumper step
• Rear cargo door Tailgate
• Rear Defrost
• Rear head restraint control 2 rear seat head restraints
• Rear head restraint control Manual rear seat head restraint control
• Rear head restraints Height adjustable rear seat head restraints
• Rear locking differential Automatic rear locking differential
• Rear reading lights
• Rear Seat Audio Controls
• Rear seat direction Front facing rear seat
• Rear seat folding position Fold-up rear seat cushion
• Rear seat upholstery Leather rear seat upholstery
• Rear seatback upholstery Carpet rear seatback upholstery
• Rear seats fixed or removable Fixed rear seats
• Rear seats Split-bench rear seat
• Rear Springs Regular grade rear springs
• Rear under seat ducts Rear under seat climate control ducts
• Rear window defroster
• Rear windshield Fixed rear windshield
• Rearview mirror Auto-dimming rear view mirror
• Remote Engine Start
• Remote panic alarm
• Requires Subscription
• Roadside warranty 60 month/100,000 miles
• Running lights Daytime running lights
• Satellite Radio
• Seat Memory
• Seatback storage pockets 2 seatback storage pockets
• Seating capacity 5
• SEATS FRONT BUCKET includes 10-way power driver and front passenger seat adjusters 2-way power lumbar control heated seat cushions and seatbacks 2-position driver memory adjustable outboard head restraints floor console and storage pockets (STD)
• Second-row windows Power second-row windows
• Security system
• Seek scan
• Selectable mode transmission
• Sequential shift control
• Service interval warning Service interval indicator
• Shock absorbers Gas-pressurized shock absorbers
• Spare tire Full-size spare tire with steel wheel
• Spare tire location Crank-down spare tire
• Speakers Bose speakers
• Speakers number 7 speakers
• Special paint Monotone paint
• Speed sensitive volume
• Split front seats Bucket front seats
• Springs front Front torsion springs
• Springs rear Rear leaf springs
• Steel Wheels
• Steering Hydraulic power-assist steering system
• Steering mounted audio control Steering wheel mounted audio controls
• Steering type Re-circulating ball steering
• Steering Wheel Audio Controls
• Steering wheel material Leather and metal-look steering wheel
• Steering wheel tilt Manual tilting steering wheel
• SUNROOF POWER with express-open includes (UG1) Universal Home Remote
• Suspension Heavy-duty ride suspension
• Suspension ride type front Independent front suspension
• Suspension ride type rear Rigid axle rear suspension
• Suspension type front Short and long arm front suspension
• Suspension type rear Leaf spring rear suspension
• Tachometer
• Tailpipe Stainless steel single exhaust
• Telematics
• Temperature display Exterior temperature display
• Tinted windows Deep tinted windows
• TIRE SPARE LT225/75R17E ALL-SEASON BLACKWALL includes 17' (43.2 cm) steel spare wheel and spare tire carrier
• TIRES LT225/75R17E ALL-SEASON BLACKWALL (STD) Includes 7 tires with (E63) Fleetside pickup box. Includes 6 tires with (ZW9) pickup box delete.)
• Tires - Front All-Season
• Tires - Rear All-Season
• Tires LT225/75SR17 AS BSW front and rear tires
• Tow Hitch
• Tow Hooks
• Tow hooks front 2 front tow hooks
• Towing class Class IV tow rating
• Towing hitch Trailer hitch
• Towing wiring harness Trailer wiring harness
• TRAILERING WIRING PROVISIONS FOR CAMPER FIFTH WHEEL AND GOOSENECK TRAILER includes additional 8-way wiring harness routed to front of pickup box
• Transfer case Electronic transfer case shift
• TRANSMISSION ALLISON 1000 6-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive electronic engine grade braking and tow/haul mode
• Transmission Allison 6-speed automatic
• Transmission electronic control
• Transmission fluid temperature warning Transmission fluid temp warning
• Transmission oil cooler Heavy-duty transmission oil cooler
• Transmission Type Automatic
• Trim rings Wheel trim rings
• Trip computer
• Trip odometer
• Turn signal in door mirrors Turn signal indicator in door mirrors
• Turn signal warning Turn signal on warning
• Variable panel light Variable instrument panel light
• Vehicle tracker
• Ventilated brakes Front and rear ventilated disc brakes
• Visor driver mirror Driver visor mirror
• Visor illuminated driver mirror Illuminated driver visor mirror
• Visor illuminated passenger mirror Illuminated passenger visor mirror
• Visor passenger mirror Passenger visor mirror
• Voltmeter
• Wheel Covers
• Wheel covers Chrome hub wheel covers
• Wheels 17 x 6.5-inch front and dual rear painted steel wheels
• Window Trim Black side window trim
• Windshield trim Black windshield trim
• Wipers Variable intermittent front windshield wipers

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 730
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 730
• Maximum Alternator Capacity (amps): 125
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Total Cooling System Capacity (qts): 16.6
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4800
• Gross Axle Wt Rating - Front (lbs): 4500
• Gross Axle Wt Rating - Rear (lbs): 8200
• Curb Weight - Front (lbs): 3638
• Curb Weight - Rear (lbs): 2902
• Gross Vehicle Weight Rating Cap (lbs): 11400
• Gross Combined Wt Rating (lbs): 23500
• Gross Combined Wt Rating (lbs): 18500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 13000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 9100
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1950
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1365
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 15900
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3975
• Suspension
• Suspension Type - Front: Independent
• Suspension Type - Rear: Multi-Leaf
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 8600
• Axle Type - Front: Independent
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 9200
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.34
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.0 x 1.8
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 1.2
• Tires
• Front Tire Order Code: QBD
• Rear Tire Order Code: QBD
• Spare Tire Order Code: ZBD
• Front Tire Size: LT225/75R17E
• Rear Tire Size: LT225/75R17E
• Spare Tire Size: LT225/75R17E
• Front Tire Capacity (lbs): 2405
• Front Tire Capacity (lbs): 2280
• Rear Tire Capacity (lbs): 2072
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 6.5
• Rear Wheel Size (in): 17 x 6.5
• Spare Wheel Size (in): 17 x - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): - TBD -
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 167.0
• Length, Overall w/o rear bumper (in): 258.7
• Width, Max w/o mirrors (in): 95.9
• Height, Overall (in): 76.1
• Overhang, Front (in): 39.4
• Overhang, Rear w/o bumper (in): 52.4
• Front Bumper to Back of Cab (in): 150.9
• Cab to Axle (in): 55.5
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 35.5
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): 9.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.8
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 64.7
• Cargo Box Width @ Wheelhousings (in): 50.6
• Cargo Box (Area) Height (in): 21.3
• Tailgate Width (in): 61.6
• Cargo Volume (ft³): 75.5
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 41.3
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 62.5
• Second Head Room (in): 40.6
• Second Leg Room (in): 39.0
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 65.5
• Summary
• Vehicle Name: Chevrolet Silverado 3500HD
• Body Style: Crew Cab 8' Fleetside
• Body Code: E63
